ZT heat-shrinkable fingerstall





Detail



Scope of application
ZT-JY series insulation heat-shrinkable fingerstall is suitable for terminal of crosslinked cable.
ZT-BD series semiconductive heat-shrinkable fingerstall is suitable for oil-paper paper insulated cable terminal or middle connection accessories.
ZT-NY series oil resistant heat-shrinkable fingerstall is suitable for oil-paper paper insulated cable terminal or middle connection accessories.


Product features
Developed by cross-linked polyolefin material;
Special forming technique to ensure surface smoothness;
Inner layer is coated with hot melt adhesive to guarantee waterproof sealing effect;
Multiple specifications to ensure request of full series of cables;
3 series of products: insulation, semiconductive and oil resistance;
Fast speed shrinkage and convenient for installation;
Standard color of insulation fingerstall is black;
Semiconductive fingerstall color is black;
Oil resistant fingerstall colors is light yellow;


ZT series specification

Model

No.

Before shrinkage (mm)

After shrinkage  (mm)

large terminal

small terminal

large terminal

small terminal

two-core

XX/ZT-2.0

33

12

10

3.5

XX/ZT-2.1

48

19

15

5.5

XX/ZT-2.2

65

23

21

8.6

XX/ZT-2.3

98

43

39

14

three-core

XX/ZT-3.00

34

19

15

5

XX/ZT-3.0

50

26

25

6.5

XX/ZT-3.1

75

35

35

10

XX/ZT-3.2

90

38

44

14

XX/ZT-3.3

105

50

56

19

XX/ZT-3.4

140

65

70

26

four-core

XX/ZT-4.0

28

12

18

4

XX/ZT-4.1

44

16

22

5.5

XX/ZT-4.2

60

25

29

8

XX/ZT-4.3

75

32

36

10

XX/ZT-4.4

85

38

43

13

XX/ZT-4.5

100

48

50

16

five-core

XX/ZT-5.0

40

12

20

4

XX/ZT-5.1

50

16

25

5.5

XX/ZT-5.2

80

25

33

8

XX/ZT-5.3

95

32

44

10
